Product DescriptionCompany Info.<>
- Model:
- cl56
- Processing customization:
- Yes
- Net weight:
- 2
- Working time:
- 300 min
- Rated concentration:
- 90 ppm
- Sterilization rate of disinfectant:
- 90 %
key components
assembly unit material requirements function description electrolyzer Ruthenium-iridium coating on titanium (MMO) Core reaction site, corrosion resistance eliminator supply High frequency switching power supply (regulated voltage 1%) Provide stable DC power brine fine filter 20 m PP meltblown filter Remove calcium and magnesium impurities and prevent scaling hydrogen separator flameproof flame arrestor Eliminate the risk of hydrogen explosion
II. Comparison of application scenarios (traditional disinfectant VS generator)
scene Sodium hypochlorite solution purchase Field Generator Preparation Waterworks disinfection High transportation costs (300/ton) Raw materials only need salt (1.2/kg) swimming pool water treatment Large fluctuation of residual chlorine Real-time adjustable concentration (0.1-2ppm) Sterilization of hospital sewage Risk of storage leakage Ready-to-use hazardous chemicals inventory Food factory equipment killing Possible residual odor No added by-products 💡Economiccases:
After the generator is used in 10,000-ton water plant, the disinfection cost is reduced from 0.25/ton to 0.07/ton, saving 500,000 + annually.
Three, equipment selection three-step method
-
Determination of available chlorine requirements
(kg) = (m³/h) × (mg/L) × 24h × 10⁻³
Example: 2000m3/h water plant (dosing 2mg/L) requires 96kg/day available chlorine -
Select cell size
Available chlorine yield Corresponding cell power salt wasting 50g/h 0.2kW 0.23kg/h 5kg/h 22kW 22.5kg/h -
Configure safety redundancy
- Power module: N+1 backup (e.g. 10kW system equipped with 2 5.5kW power supplies)
- Electrolyzer: dual channel independent operation (single channel failure still maintains 50% capacity)
